End Table (pt. 1)

Background

Eight years ago, Becky really wanted a new coffee table.  In my bachelorhood I had purchased the old coffee table with 2 “matching” end tables for $50.  They didn’t really work in our 1100 sq ft condo in the city.  In our suburban pad – comical.  Picture Lego dinner table in the middle of Staples arena.

So we went to Berkeley Mills, and Beck found a table she loved.   I’ll admit – it was beautiful…and $5,000.  For a table.  $5,000 table.  Seriously.

car

Here is a 10 year old *car* I just found when I Googled “$5000 car”. Its $4900, btw

So I justified buying some toys for the garage.  I already had a decent table saw (a contractor saw w/ good tolerances).  I bought a planer.  $500 in.  That’s 10% of the cost of the Berkeley mills table.  I’m ahead of the game.

Anyway, 2 months, lots of cursing and mallet-pounding later Becky has her coffee table.  See Joey below next to the object in question 8 years later.

003

…waiting for food to fall…

The table has been with us for years.  We taped “bumpers” on the corners when Emma was little.  When Ryan was a toddler we were experienced/tired parents so we just kept an eye on him.  Both kids teethed on it (I’ll remind them of that offense someday when they are changing my “Depends”) but it is now part of our home.

After I competed the table, Becky next request was naturally “….when do I get the end tables?”.   My promise was “next week”.

Fast forward nearly a decade, another kid…no end table.  Now I’m changing jobs and am going to steal a week to refurbish the workshop and make those end table(s).

Basic Design

Beck and I disagree, but with custom furniture I think it all should be custom – so I’m going to make only one.   The effort to make 2 vs. 1 is like an extra 25% – but I’m moderately confident in my position

I wanted the end table to feel like it is part of the same “set” as the coffee table.  The aspect ratio and other design elements would have to change, but not the basic “cherry frame with contrasting maple inside” idea.   The coffee table design (totally stolen from Berkeley Mills) was very rectilinear, so I’d have to avoid curves.   The basic idea was the have a single maple “box” in the middle of a cherry frame.  I thought it’d be cool to have the box appear “too deep” yet not reveal the maple when viewed from anything but a <45 angle.   I sketched some things on paper, tried to figure out either multiple dimensions (the “hole” is 2x the width of the sides), or creative use of the golden rectangle.  Rather than scan in these sketches, I’ve reproduced the basic idea in MS Paint:

diagram

Dude – what did you expect from an attempted isometric drawing in Paint?

Getting Started

I won’t show you the “before” and “after pictures of the garage.  Think “Hoarders” but with kid crap,  bikes, and camping gear.  Below is the wood, planed and joined sitting on plastic (at this point, scratches and dirt are the enemy.  I only put the wood on surfaces of plastic or cloth).

005

The cherry I planed until it had the ~ dimensions from my original sketches.  For the maple, I had to be more precise (more on that later).  I planed until it was clean/flat, then put the dado on the tablesaw and tried to match the thickness.  After one or two more passes (it is way easier to remove wood than tweak the dado shims), I had a dado cutting the exact thickness of the maple.

007

This really isn’t part of the discussion, but I just wanted to show off how huge the shavings pile was in the end

Right before I was about to cut the maple for the inner-box, it occurred to me to sand the sides.  It is way easier to do this when it is still  an 8′ board vs. a bunch of cut pieces.  Note I sanded vs. planed because I suck at finish planing.

008

Tip – make every fixed surface in your garage the same height – usually the height of the table saw. Then, you can do goofy things like shown above.

So I cut the 4 maple boards to a larger dimension than I’d need.   Dado time.  After the first cut, I used a scrap of the same maple to lock the two boards together.  The distance between the dado cuts has to be the same on each pair of boards in the box.  The scrap “key” is very handy.

010

Note due to the bevel (you’ll see shortly), the depth of the cut in each of the board pairs wasn’t the same.  Repeat and hope like hell you got the height right.  Even if you leave extra material, you’ll never get completely into the same slot on the dado.

030

Dead nuts!  Note “dead nuts” is a machinist expression I learned at my first job meaning “very precise”.   It doesn’t have anything to do with, as my kids would say, someone’s “ding ding”.

040

Now I have a box.  Kind of cool.  Time to remove ~ 3/4″ of the protruding arms of the box.

050

This is one of those tricky cuts where you don’t have a natural surface to butt up against.  It has to be eyeballed.   Note below I’m still using that scrap “key” to ensure the boards are perfectly aligned.

060

To keep the dado from tearing out the back on each pass, I had a sacrificial backing board clamped between the work pieces and the miter guide.   After a bunch of passes, it looks like that thing ‘Kicking Bird’ gave to Kevin Costner at the end of “Dances with Wolves”.

070

“…hmmm…but how does it smoke?” “I’ve never smoked it…”

Bunch more easy dado cuts (only one of the boards was a challenge to align), and we have our roughed box.

080

Below is the corner I was going for.  So far, so good.

090

Miter the corners.  This was also tricky to align, but if they aren’t exactly the same no one will really notice.  Note the sacrificial scrap under the work piece.

100

The basic maple “chassis” is shown below.  It was kind-of cool to be able to dry-fit it and pull it apart again.  Like Lincoln logs or something else Ryan would play with.  Except those cost $10 and this cost more in raw wood and took me 2 days.

150

Now its time to cut the frame pieces from cherry.  One more quick “measure-twice, cut once” exercise I somehow remembered to do:

roughBoxOhShit

Oh shi….

Somehow in all the excitement, I somehow measured the inside (or outside) of something and added 2x the width of the sides.    The cherry wasn’t wide enough to still accommodate my original design (“…hole is twice the width of the sides…”) but fortunately I had enough length to cover the perimeter.    So much for my “multiples of dimensions, golden ratio” flacknoge.

greek-ancient-greek-clothing-2

“Bill – you suck at this ‘pleasing design’ stuff” – Pythagoras



Hosting Apps from Github

I’ve been using github for some time to host code.  What I never knew was that I could create html pages (a “site”) for each project, as well as my account as a whole.  I got on the trail of this feature when I noticed my favorite game, 2048, was hosted on a “github” domain.

There is a reserved branch name (“gh-pages”)  which is the root of your project’s site.  Anything in that branch will be served-up from the “<your_user>.github.io/<project>” sub-domain.  For example, today I registered “billsco” as a user (ditching my old, crufty github junkyard).  I now have billsco.github.io as the page for my account (in the specially named “billsco.github.io” repository I created).  For the “Dot Game”, I now have billsco.github.io/dotGame.  All are addressable from the browser, and don’t show the contents as a repository but rather as a web site.  Neat.

What I could not work out was how to keep my apps on “master” yet serve them up from github.io.  I’ve decided to just do development out of “gh-pages” so my changes are instantly visible after a push.   I used my landing “billsco.github.io” page as a holder for links to those apps.

As a reminder for myself and pointer to others, here is the recipe such that a “master” isn’t created for a repo (minimizing the chances of screwing-up and not committing to “gh-pages”).

  • Create a new repo (“foo”) using the github UI.  Don’t add the “README.md” or any other files.
  • On your local machine, create a repo with the same name, and create the “gh-pages” branch:
$ mkdir foo;cd foo
$ git init
$ git commit --allow-empty -m "Something to branch from"
$ git checkout -b gh-pages
$ git remote add origin https://github.com/<your_user>/foo.git
$ git push -u origin gh-pages
  • From now on when you clone, you should automagically be in the “gh-pages” branch.

Log in with…

I decided to add “Log in with…” functionality to a portion of the site.  You’ve seen it – a set of buttons “Log in with Facebook”, “Log in with Google +”, etc.  What am I protecting?  Nothing right now.  Just wanted to see how it worked.

So I started like I do all projects and Googled for what I wanted:

liwgSearch

Googling “log in with Google” gave me the above results.  I clicked on the first link which brought me to a page which instantly declared that it was presenting deprecated information:

result

I’m not trying to knock Google.  They are a great company, and their search engine is an indispensable tool.   As a developer, I can search arcane error messages or phrases involving code and always get an answer.  It’s just funny that the first time I use Google to search for how to develop against Google it falls short.

btw: The right answer was only a few clicks away.

Fence post Problems

Only a subset of developers suffer from this – but I’m one of them.  I always create bugs involving fence post problems.  You know the fence post problem?  You’ve got 100 feet to be fenced-in.  Fence posts are to be spaced 10 feet apart.  How many fence posts do you need?  100/10=10, right?  Wrong.  You need 11.

Farm-Fence-2



As background, I just created a new game.  It’s based on a paper game every parent who has ever been to a chain restaurant knows.  You enter “Chotskie’s” and your kids are dutifully issued their paper menu and crayons.  Often the back of the menu contains a game with a matrix of dots.  The objective of the game is to connect dots, forming boxes.  Each player must create a new connection between adjacent dots during their turn.   If the player completes a square they color that square with “their” crayon, and create one more line.  If another box is closed – repeat.  The object is to close more boxes than your opponent (brother, sister, mean-dad, etc).

So back to fence post problems.  Developers are used to dealing with arrays.  Arrays start at 0?  No sweat.  We warped our brains into starting at “0” years ago.  But consider the sophisticated mock-up of the game below:

gameboard



In “dot units”, it is 2×2.  That’s the rub.  Describing the system in terms of the intersections vs. the lines messes with traditional array thinking (at least for me).  I also decided to record lines (to tell if someone can create a new line) in arrays.  Since the lines aren’t directional in this game, I decided on the convention of “Left to Right” (horizontal) and “Top to Bottom” (vertical).  Connecting the first horizontal dot with the second (or vice versa) would be recorded at index “0”.   So for the above picture I need a 2×2 array?  Nope:

gameboard2



So my puny brain needs a 3×3 array to handle a “2×2” game.  Auggg.  After a few “+1”, “-1” bugs, I did get it working.  Emma actually sought me out to play a few rounds last night.  Nice.



Attack of the green tomatoes

A few weeks back I decided I needed to create a game to delight my kids.  That made the problem not technical but one of inspiration.  I decided to stew on this for a few days.  Then someone showed me 2048.  This set me back.

First off, it is massively addicting.  When I got the “2048” tile I was momentarily proud then realized I needed to stop (“…what the hell happened to the last 4 hrs?”).   Beyond cycles lost to arranging ^2 tiles, I was floored by the game’s simplicity.   One “level”, no “achievement”.  Just a simple model like “tetris” or Rubik’ Cube.  That’s when I realized my hubris.  Just because I decided to devote some nocturnal cycles to JavaScript doesn’t mean I can instantly entertain.  This may take some time.

So the exercise is mental – examine what I see in things (games, designs, nature) and think of how they may entertain.  In the mean time, I created a simple game to continue to improve my technical skills.  It is more complete than my last effort, but still something of a boring idea (moving a little sprite trying to avoid green balls, eat bacon).   It was nice to work on it with the kids.  Emma spent some real time with me designing the sprite in Inkscape, and Ryan with me on the code.

“Dad – why doesn’t the person fall when they get hit?”

“I think I need to add ‘gravity’ but I need to figure out how to do that”

“I think I saw ‘gravity’ on that page you were looking at [the documentation].  Here [grabs the mouse] I think it was back one page…”

He’s really into it.   He also came up with the name – “attack of the green tomatoes”.

It is now posted, as well as the source on github.  It is totally too big (didn’t really work to reduce images).  I had some fun creating a pattern for “levels”, and parameterized the input to the level class so it could be reused with “harder” arguments as a more advanced level.   Maybe I’ll add a few more level types, or perhaps call it quits and move onto something more interesting.



Why write codeWhy do side projects

I’ve been working on my “real” HTML5 game.  By “real” I mean not text based.  Things moving around the screen, physics, tap/drag, etc.  On Friday I lost steam and had time to reflect on why over the weekend.

I do these little projects to explore new technologies.  An analogy is like learning to drive a motorcycle.  You can go to the CSM parking lot on Saturday morning and go in circles (take a class), or you can learn the basics then start riding (self directed learning).  Pick an arbitrary  destination then start moving.   This is what I’ve been doing for years.  I pick a target, but always knowing that the journey was the real goal.  Lacking a real definition of “done”, I’d stop the journey when I’d decided enough learning had been accomplished.

This is a common way to “keep up” with technology, but I’m missing something to be passionate about.  My wife once told me she was jealous because my job was my hobby.   I want to restore that passion via these projects (more on “physical” or “real world” engineering sucks compared to vs. “computer” engineering in a later post).

What I realized on Friday was that I was building a game without a design.  Literally.  I was putting things on the screen that looked interesting (to me), having them collide, playing sounds – but I lacked an actual plan for what the game would do.

I’m going to pause and design a real game before I continue.  As a parent, I have a reflex to mandate the game incorporate some form of learning.  Something that reinforces the multiplication tables for my boy or factoring for my girl.  However, this distracts from the goal of entertainment.   Am I a bad parent because I want to make a toy?   No.  We send them to school, work with them at home, read to them before bed.  We’re doing our job – everything doesn’t have to strive to push them closer to getting to college.   So my new goal for this project is changing from “explore technology and maybe produce something 1/2 finished” to “entertain my kids”.
